CSPower battery discharge voltage VS remaining battery capacity (Technology Support)

To All CSPower Valued Customers,

Comparison of the relationship between battery discharge voltage and remaining battery capacity (when a fully charged battery is discharged at 10HR at 25°C).

The following data will have different performances depending on the battery, battery state of charge, battery usage environment, and battery usage stage.

It is for reference only.

When the discharge cut-off voltage is 12.50V, the battery has 80% remaining capacity;
When the discharge cut-off  voltage is 12.25V, the battery has 60% remaining capacity;
When the discharge cut-off  voltage is 12.13V, the battery has 50% remaining capacity;
When the discharge cut-off  voltage is 12.00V, the battery has 40% remaining capacity;
When the discharge cut-off  voltage is 11.65v, the battery has 20% remaining capacity;
When the dischargecut-off  voltage is 11.00v, the battery has 0% remaining capacity;

It is recommended that customers set the discharge protection voltage to about 11.65V (12V battery).

Further more details on battery usage, please feel free to reach us.
