CSPower CL2-2000 Deep Cycle AGM Battery

Short Description:

CSPOWER CL series of 2V VRLA AGM batteries upto 2V3000Ah are recognized as the most reliable and high quality battery system in the industry.
They are designed with advanced AGM (Absorbent Glass Mat) technology, Long service life designed with 10-15 years, the batteries comply to the most popular international standards.

• Capacity: 2V100Ah~2V3000Ah
• Designed floating servive life: 10-15 years @25 °C/77 °F.
• Brand: CSPOWER / OEM Brand for customers Freely
• Certificates: ISO9001/14001/18001; CE/IEC 60896-21/22 / IEC 61427

Send email to us Download as PDF

Product Detail

Technical Data

Product Tags

CL2-2000
Nominal Voltage			2V(1 cell per unit)
Design Floating Life @ 25℃			15 Years
Nominal Capacity @ 25℃		10 hour rate@200.0A,1.8V	2000Ah
Capacity @ 25℃		20hour rate (106A,1.8V )	2120Ah
		5 hour rate (354A,1.75V )	1770Ah
		1 hour rate (1210A,1.6V )	1210Ah
Internal Resistance		Full Charged Battery@ 25℃	≤0.12mΩ
Ambient Temperature		Discharge	-15℃~45℃
		Charge	-15℃~45℃
		Storage	-15℃~45℃
Max.Discharge Current			@ 25℃ 4000A(5s)
Capacity affected by Temperature (10 hour )		40℃	105%
		25℃	100%
		0℃	85%
		-15℃	65%
Self-Discharge@25℃per Month			3%
Charge (Constant Voltage) @ 25℃	Standby Use	Initial Charging Current Less than 300A Voltage 2.23-2.27V
	Cycle Use	Initial Charging Current Less than 300A Voltage 2.33-2.37V
Dimension (mmmmmm)	Length 490±1 * Width 350±1 * Height 342±1 (Total Height 383±1)
Weight (kg)	130±3%

Previous: CSPower CL2-1500 Deep Cycle AGM Battery

Next: CSPower CL2-2500 Deep Cycle AGM Battery

CSP-MODEL	Voltage (V)	Capacity (Ah)	Length (mm)	Width (mm)	Height (mm)	Total Height (mm)	Weight (kg) (±3%)	Terminal	Bolt
CL2-100	2	100/10HR	172	72	205	222	5.9	T5	M8×20
CL2-150	2	150/10HR	171	102	206	233	8.2	T5	M8×20
CL2-200	2	200/10HR	170	106	330	367	13	T5	M8×20
CL2-300	2	300/10HR	171	151	330	365	18.5	T5	M8×20
CL2-400	2	400/10HR	211	176	329	367	26.1	T5	M8×20
CL2-500	2	500/10HR	241	172	330	364	31	T5	M8×20
CL2-600	2	600/10HR	301	175	331	366	37.7	T5	M8×20
CL2-800	2	800/10HR	410	176	330	365	51.6	T5	M8×20
CL2-1000	2	1000/10HR	475	175	328	365	62	T5	M8×20
CL2-1200	2	1200/10HR	472	172	338	355	68.5	T5	M8×20
CL2-1500	2	1500/10HR	401	351	342	378	96.5	T5	M8×20
CL2-2000	2	2000/10HR	491	351	343	383	130	T5	M8×20
CL2-2500	2	2500/10HR	712	353	341	382	180	T5	M8×20
CL2-3000	2	3000/10HR	712	353	341	382	190	T5	M8×20
Products will be improved without notice, please contact sales for specification in kind prevail.
